DESCRIPTION

Overview

Basic Info.

Model NO.	MHT50-1300-19
Voltage	380V
Automatic Grade	Automatic
Principle	Large Deformation
Certification	ISO9001, CE
Warranty	12 Months
Customized	Customized
Condition	New
Shortest Part	90
Number of Rolls	19
Application	Copper Plate,Stainless Steel Plate.Steel
Service	OEM&ODM Available
Leveling Speed	0-10m/Min
Rated Thickness	0.8-4.0mm
Maximum Thickness	8.0mm
Roll Diameter	50mm
Width	0-1300mm
Transport Package	Wooden Case Package
Specification	Please consult customer service
Trademark	MAHATMA
Origin	China
HS Code	8462219000
Production Capacity	500 Set/Year

Packaging & Delivery

Package Size 285.00cm * 210.00cm * 210.00cm Package Gross Weight 3810.000kg

Product Description

CNC High-precision straightening machine equipment with 19 Rollers

Model details

Model	MHT50-400-19	MHT40-600-19	MHT50-800-19	MHT50-1000-19	MHT50-1300-19	MHT50-1600-19	MHT50-2100-19
Width	0-400mm	0-600mm	0-800mm	0-1000mm	0-1300mm	0-1600mm	0-2100mm
Roll diameter	50	50	50	50	50	50	50
Rated thickness	0.8-4.0mm	0.8-4.0mm	0.8-4.0mm	0.8-4.0mm	0.8-4.0mm	0.8-4.0mm	0.8-4.0mm
Maximum thickness	8.0	8.0	8.0	8.0	8.0	8.0	8.0
Number of rolls	19	19	19	19	19	19	19
Shortest part	90	90	90	90	90	90	90
Leveling speed	0-10m/Min	0-10m/Min	0-10m/Min	0-10m/Min	0-10m/Min	0-10m/Min	0-10m/Min
Voltage	3-phase 380v	3-phase 380v	3-phase 380v	3-phase 380v	3-phase 380v	3-phase 380v	3-phase 380v

Normal MHT CNC High precision Leveling Machine	MHT10	10	0.03-0.6	100-300	31	20
	MHT15	15	0.08-1.0	100-600	31	30
	MHT20	20	0.3-1.2	200-1600	23	40
	MHT30	30	0.5-2.0	400-3000	23	60
	MHT40	40	0.6-3.0	400-3000	21	70
	MHT50	50	0.8-4.0	400-3000	19	90
	MHT60	60	1.0-6.0	400-3000	21	100
	MHT80	80	2.0-8.0	400-3000	19	130
	MHT100	100	3.0-12.0	400-3000	19	160
	MHT120	120	4.0-16.0	400-3000	19	190
	MHT150	150	6.0-25.0	600-3000	19	240
	MHT200	200	8.0-30.0	800-3000	15/19	310
	MHT250	250	10.0-40.0	1000-3500	15/19	390
	MHT300	300	12.0-50.0	1000-4000	15/19	480

Drawings

The Leveling principle and how should we leveling it?

Detailed Photos

CNC Leveling machine functionThe CNC precision leveller uses the "Bauschinger effect" of the material to bend the sheet metal several times, regardless of the degree of original bending, under the conditions of a large elastic-plastic bending, gradually reduce bending deflection, so that a variety of original curvature gradually become a single curvature, and eventually straighten it to meet the process requirements of the leveling accuracy.Numerical control leveling machine has been widely used in industry, with advanced technology, high leveling accuracy, wide range of technology, high degree of automation, reliable and stable work under high strength, etc. , after a series of alternating bending of metal plates, through motor and PLC control of each leveling drum under precise control of the pressure, the elimination of internal stress, the leveling effect caused by different stress in different parts of the plate is not ideal, thus achieving high precision leveling.Compared with other levelling methods, the control system of this machine has the functions of storing, calling, editing process and equipment parameters, and has the function of misoperation identification and early warning. When in use, on the operating table, you can set the reduction amount of the inlet and outlet according to the parameters such as plate thickness and plate width or the parameters already in the database, so as to realize the electric adjustment of the working roller, the inlet and outlet clearance, etc. , it can be adjusted and corrected by hand.This machine adopts Panasonic PLC controller and Delta frequency converter to control the running speed. All actions of the machine are controlled by the operation table. The touch-type man-machine interface display screen makes the operation panel easy to understand, install emergency set switch at four prominent positions at the machine entrance and exit to ensure safe operation! And equipped with digital display displacement, the operation is very simple and rapid. It only takes a few seconds to straighten out high-precision and complicated hardware that usually takes a long time to be hand-leveled.CNC leveller is the first choice for vehicle manufacturing, locomotive manufacturing, construction industry, medical technology industry, chassis manufacturing, textile machinery, sheet metal processing, etc. . It plays an important role in verticality, parallelism, appearance and precision of industrial structureDetals Operation:Step 1: Recording the material thickness and plane distortionStep 2: Turn on the power and input the material thickness(If the material thickness is 1mm, input 1 in the NC interface to set the left feeding value, right feeding value, left discharging value and right discharging value)Step 3: Put the material into the leveling machine for leveling(Click Forward start and put the material into the leveling machine for leveling)Step 4: Check the flatness of materials(Put the material on the marble platform and measuring material accuracy. If it fails to meet the leveling requirements, according to step 5)Step 5: Adjust the accuracy again(According to the adjustment of front tightening and rear loosening, adjust the left feed settingvalue and right feed setting value downward by 0.5mm, and the left and right discharge do not move)Step 6: Check the flatness of the material again to achieve the effectStep 7: Finish debugging, turn off the power supply and clean the interior and surface of theFAQ

• 01.How much do you charge for the services

  One purchase, lifetime service. We always provide free online problem-solving, and if the warranty period is exceeded, all equipment parts can be purchased at the factory price.

• 02.Do you have after sales support?

  Yes, we are happy to give advice and we also have skilled technicians available 24hrs online. We need your machines running in order to keep your business running.

• 03.I am not sure if this machine suitable for my work?

  Don't worry, just tell me your working materials, specifications of workpieces, like width, thickness and length, then I will recommend you the most suitable machine for you.

• 04.Are you factory or trading company?

  We are factory, which manufactures CNC Leveling Machines , with 20 years experience in CNC machine's industry.

• 05.How can i do if the machine goes wrong?

  If confronted with such problems,online service is offered,you could contact our sales. Also,we offer engineer delivery service.Please contact us asap and don't try fix the machine by yourself or someone else. We will response within 12 hours as quick as we can to solve it for you.
